Minimum working weight, flange mounted 870 kg (1)
Weight 710 kg
Working length 2004 mm
Impact rate (frequency) 550 – 950 bpm
Operating pressure 140 – 160 bar
Pressure relief min 220 bar (2)
Pressure relief max 240 bari
Oil flow range 80 – 140 l/min
Back pressure max 10 bar
Input power 37 kW
Tool diameter 105 mm
Pressure line connection (IN) ORFS ( 1 7/16-12 UN )
Return line connection (OUT) ORFS ( 1 7/16-12 UN )
Pressure line size 19 mm (3)
Return line size 19 mm (3)
Grease connection Tema 2520
Optimum oil temperature 40 – 60 °C
Allowed oil temperature range -20 – 80 °C
Optimum oil viscosity at operating temperature 30 – 60 cSt
Allowed viscosity range 20 – 1000 cSt
Carrier weight, optimum 11 – 17 t
Carrier weight, range 10 – 19 t (*4)
Noise level, measured (2000/14/EC) 120 dB(A)
Noise level, guaranteed (2000/14/EC) 124 dB(A)
*1 Includes average mounting bracket and standard tool
*2 Minimum setting = actual operating pressure + 50 bar
*3 minimum inner diameter
*4 Check carrier allowed attachment weight from carrier manufacturer. Check application requirements.
Delivery charge includes delivery and collection within 30 miles radius of Penrith. If distance required is further, please message us.
